Miele wall type extractor DA7198 W Triple Grey

1999 €
In Stock
SKU: 10744640
Wall mounted cooker hood with energy-efficient LED lighting and light-touch switches for easy use. Unique design with 3 curved glass surfaces, 880 mmmm wide Unique user convenience – Con@ctivity Energy-efficient and uniform illumination - 2 LED spotlights Powerful - 600 m3/hm3/h on the booster setting Energy-efficient and quiet - powerful ECO motor

More product information

Highlights

ACTIVE FILTER

Active AirClean filter

A completely odour-free kitchen

Miele recirculation mode cooker hoods always require an Active AirClean filter in addition to the grease filter. This Miele filter removes odours efficiently and long-term.


Stainless steel grease filters (10-layer)

STAINLESS STEELAesthetically pleasing and highly functional
Miele cooker hoods are equipped with a 10-ply stainless-steel grease filter. The top layers and filter frame are made of high-quality stainless steel. "When you conveniently clean the grease filters in the dishwasher, no visible discolouring will occur," and the Miele grease filters keep their high-quality appearance for a long time.

Miele CleanCover

MIELE CLEAN COVERConvenience and safety in detail
Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with cables and motor components. Miele attention to detail - for your convenience and safety.


LED spotlights

LED SPOTLIGHTSPowerful lighting with minimum energy consumption
LED spotlights are an optical highlight and are environmentally friendly. A Miele LED spotlight consumes only 3 or 4.5 W and thus saves a lot of electricity. Miele LEDs illuminate the hob with a warm, natural and even light.

Perfect processing

PERFECT PROCESSINGVisible quality
Miele cooker hood canopies and towers are made from high-quality welded and polished stainless steel. Even from the outside you can see the quality of a Miele hood: Precise contours and precision joints are typical characteristics of Miele cooker hoods. Enjoy perfect workmanship!


Handcrafted in Germany

HANDCRAFTED IN GERMANYEach Miele cooker hood is unique.
Almost all Miele cooker hoods are developed at Miele's Arnsberg plant and are, for the most part, hand-crafted. Each cooker hood is unique. Every stage of the manufacturing process involves a certain amount of manual craftsmanship: From shaping the steel to welding and polishing. The commitment of employees, their expertise, creativity and desire to excel have contributed greatly to Mieles position in the market today.

Design flexibility

DESIGN FLEXIBILITYTimeless purism
Miele offers cooker hoods in a large variety of designs with many functional features - perfect technology for every situation. Miele cooker hoods have characteristic accents without being intrusive. Clean lines, well thought-out functions and timeless design.


Specifications



Product data sheet

Extraction (not with external variants)
Air throughput in Level 1 (m³/h) 160
Air throughput in Level 2 (m³/h) 260
Air throughput in Level 3 (m³/h) 375
Air throughput in Booster level (m³/h) 600
Sound power in Level 1 (dB(A) re 1 pW) 40.00
Sound power in Level 2 (dB(A) re 1 pW) 51.00
Sound power in Level 3 (dB(A) re 1 pW) 60.00
Sound power in Booster level (dB(A) re 1 pW) 72.00
Sound pressure in Level 1 (dB(A) re 20 µPa) 25.00
Sound pressure in Level 2 (dB(A) re 20 µPa) 36.00
Sound pressure in Level 3 (dB(A) re 20 µPa) 45.00
Sound pressure in Booster level (dB(A) re 20 µPa) 57.00
Fan
Dual-action fan
ECO motor (DC motor)
Recirculation
Air throughput in Level 1 (m³/h) 85
Air throughput in Level 2 (m³/h) 165
Air throughput in Level 3 (m³/h) 265
Air throughput in Booster level (m³/h) 375
Sound power in Level 1 (dB(A) re 1 pW) 46.00
Sound power in Level 2 (dB(A) re 1 pW) 57.00
Sound power in Level 3 (dB(A) re 1 pW) 66.00
Sound power in Booster level (dB(A) re 1 pW) 75.00
Sound pressure in Level 1 (dB(A) re 20 µPa) 31.00
Sound pressure in Level 2 (dB(A) re 20 µPa) 42.00
Sound pressure in Level 3 (dB(A) re 20 µPa) 51.00
Sound pressure in Booster level (dB(A) re 20 µPa) 61.00
Installation notes
Extraction ducting connection at top
Extraction ducting connection at rear
Extraction connection at top and rear
Diameter of extraction ducting connection in mm 150
Safety
Safety switch-off
Single pane tempered glass
Technical data
Overall height for extraction mode and external mo 440
Overall height for recirculation mode cooker hoods 440
Canopy width in mm 880
Canopy height in mm 440
Canopy depth in mm 433
Minimum height above electric hobs in mm 450
Minimum height above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650
Net weight in kg 21.00
Length of supply lead in m 1.50
Standard plug fitted
Hard-wired connection
Total rated load in kW 0.11
Voltage in V 230
Fuse rating in A 10
Frequency in Hz 50
Number of phases 1
Lighting
LED
Number x W 2 x 3 W
Light intensity in Lx 0 null
Colour temperature in K 0 null
Dimmer function
Appliance networking
Miele@home
Automatic function Con@ctivity 3.0
MobileControl
Filter system
Number of dishwasher safe stainless-steel grease filters (10-ply) 1
Efficiency and sustainability
PowerManagement system
ECO package
Cleaning convenience
Easy-to-clean canopy interior – CleanCover
User convenience
Power levels (number without Booster level)  3
Electronic controls
Programmable Booster level switch-off
Run-on time 5/15 min.
Light-touch switches with LED
Grease filter saturation indicator programmable
Active charcoal filter saturation indicator programmable
Booster level
Grease filter saturation indicator
Design
Colour Graphite grey
Operating modes
Type of air guide Convertible
Construction type
Wall mounted cooker hood
